Rotary Drilling Rig Foundation Drilling Belling Bucket For Piling Machinery Expand Bore Hole Diameter
JTHL Drilling Tools Belling Bucekts
Drilling Augers Buckets Tools Two Wing Belling Bit Used for Rock Drilling Rig
Main Application:
Soil. Medium Rock
Competitive Advantage:
- Kelly box size as per customer's demand
- Bucket thickness can be made 16mm or 20mm as customer's demand
- The single bottom plate thickness:50mm
- The double bottom plate thickness:40/50mm
- Teeth type:V19 or V20
Specification:
| Technical Specification of Two Wing Belling Bit | ||||
| Size | Drilling dia(mm) | Belling Dia(mm) | Length(mm) | Length(mm) |
| KD600 | 560 | 1200 | 1900 | 1550 |
| KD800 | 760 | 1600 | 2160 | 1700 |
| KD1000 | 960 | 2000 | 2650 | 1950 |
| KD1200 | 1160 | 2400 | 3050 | 2050 |
| KD1500 | 1460 | 3000 | 3600 | 2600 |
| KD1800 | 1760 | 3600 | 3900 | 2650 |
| KD2000 | 1960 | 4000 | 4200 | 2850 |
Rotary Drilling Rig Foundation Drilling Belling Bucket for Piling Machinery expand bore hole diameter
We are manufacturer for piling rig kelly bars and spares for more than 17 years old.
